The DA4090 is a high quality antenna distribution solution for use in pro audio applications such as live performance - musical/theatrical – HOW and audio-video integration.
Designed with a net 0dB amplification thereby eliminating split-attenuation

Minimal amplification is applied to reduce the risk of unwanted inter-modulation interference. Integrated DC power distribution conveniently distributes 12VDC to drive up to four CAD Audio receivers. All antenna connectors are BNC-type for easy plug and play compatibility.

The DA4090 comes complete with RF patch cables for four receivers, rack ears and the appropriate power cables.

Specifications
Frequency Range UHF 470 - 960MHz
Impedance 50Ω
Gain 0dB
AC Power 100 - 240V, 60Hz
DC Output DC 12 - 15V, 3.6A
Antenna Power 12V
Dimensions 16-1/2” x 7-13/16” x 1-3/4”
Weight 3lbs 7oz [1.56kg]
