Description
The Netron EP4 is a compact Ethernet to DMX gateway with four RDM compatible ports. It is configurable via its internal web remote and powered over Ethernet or via the USB-C connection.
Key Features
- RDM, Artnet and sACN support
- Factory and user presets for plug and play setups
- POE or USB-C powered
- 99 Internal cues with fade and delay time
- Remote configuration via internal webpage
- Powder-coated compact aluminum housing
- Connect to ONYX PC for a full four Universe Solution
For technical details and documentation of NETRON devices please visit
Specifications
Mounting
- Standalone
- Truss-mount (M10 or M12 mounting hole)
- Wall-mount horizontal or vertical (included)
- DIN Rail horizontal or vertical (included)
Connections
Front
- (4) 5pin DMX/RDM optically isolated ports / Ports are bidirectional for DMX In and Output
Back
- (2) Locking RJ45 Ethernet network connections (1x POE)
- USB-C power option (5V, 2A)
Physical
- Length: 133.5 mm (5.3 in.)
- Width: 118 mm (4.6 in.)
- Height: 42 mm (1.65 in.)
- Weight: 0.5 kg (1.1 lbs)
Electrical
- USB-C 5V
- POE 802.3afPower Consumption 3.8W
APPROVALS / RATINGS
- CE | FCC | IP20
Specifications and documentation subject to change without notice.
Additional Details
- SKU:
- NRE023
- UPC:
- 810008260678
- Condition:
- New
- Width:
- 6.00 (in)
- Height:
- 4.00 (in)
- Depth:
- 4.00 (in)
