Hydro Hybrid — IP65 Beam / Spot / Wash Hybrid Moving Head

MSRP:
Was:
Buy Now! Buy Now: $4,999.99
(You save )
(No reviews yet) Write a Review
44 people looking at this.
Free Shipping - Usually shipps next business day!

Description

The ADJ Hydro Hybrid** is a rugged, weather-resistant IP65-rated moving head luminaire that flexibly combines beam, spot, and wash functionality in a single unit. Powered by a 420W Osram SIRIUS HRI discharge lamp, it’s built for touring, outdoor events, festivals, and demanding installations. With full CMY color mixing, gobos, prisms, motorized zoom and focus, and a robust enclosure, it offers creative control and dependable performance in all conditions. :contentReference[oaicite:0]{index=0}

Light Source & Output

  • 420W Osram SIRIUS HRI discharge lamp :contentReference[oaicite:1]{index=1}
  • Up to ~14,416 lumens (typical published output) :contentReference[oaicite:2]{index=2}
  • Full CMY color mixing system + 12-position color wheel (including CTO filters & UV) :contentReference[oaicite:3]{index=3}

Optics, Zoom & Beam Modes

  • Motorized zoom / variable beam angles:
    • Beam mode: approx. 1.6° – 17.7° :contentReference[oaicite:4]{index=4}
    • Spot mode: approx. 3.1° – 39.2° :contentReference[oaicite:5]{index=5}
  • Heavy frost filter for transforming beam/spot into wash output :contentReference[oaicite:6]{index=6}
  • Two gobo wheels (rotating + static) with interchangeable glass/metal patterns :contentReference[oaicite:7]{index=7}
  • Dual-plane prism effects (8-facet circular, 6-facet linear), overlay capability :contentReference[oaicite:8]{index=8}
  • Animation wheel for dynamic projection effects :contentReference[oaicite:9]{index=9}

Control & Effects

  • Standard DMX control (multiple channel modes) :contentReference[oaicite:10]{index=10}
  • RDM compatible for remote addressing & device management :contentReference[oaicite:11]{index=11}
  • Motorized focus, iris, strobe, and dimming with selectable curves :contentReference[oaicite:12]{index=12}
  • Preprogrammed macros and automated / sound-active modes :contentReference[oaicite:13]{index=13}
  • Aria X2 wireless management support (e.g. Bluetooth, OTA updates) :contentReference[oaicite:14]{index=14}

Electrical & Power

  • Power input: AC 100–240V, 50/60Hz :contentReference[oaicite:15]{index=15}
  • Max power consumption: ~580W :contentReference[oaicite:16]{index=16}
  • Operating temperature range: –20 °C to 45 °C (–4 °F to 113 °F) :contentReference[oaicite:17]{index=17}

Housing & Mechanical

  • IP65-rated enclosure — sealed and rugged for outdoor deployment :contentReference[oaicite:18]{index=18}
  • Die-cast steel construction with durable housing :contentReference[oaicite:19]{index=19}
  • Pan/tilt mechanical locks for transport security :contentReference[oaicite:20]{index=20}
  • Integrated carry handles for easier handling :contentReference[oaicite:21]{index=21}

Dimensions & Weight

  • Length (depth): 11.4” / 290 mm :contentReference[oaicite:22]{index=22}
  • Width: 16.31” / 414.3 mm :contentReference[oaicite:23]{index=23}
  • Height: 29.17” / 741 mm :contentReference[oaicite:24]{index=24}
  • Weight: 69.7 lbs / 31.6 kg :contentReference[oaicite:25]{index=25}

What’s Included

  • Hydro Hybrid moving head fixture
  • PowerCON TRUE1 locking power cable
  • Omega brackets (for truss / mounting)
  • User manual

Use Cases

  • Outdoor concerts, festivals, tours & live events
  • Permanent outdoor installations (stadiums, theme parks)
  • Large indoor venues requiring weather-resistant lighting
  • Hybrid lighting setups needing beam, spot, wash in one unit

Notes & Disclaimers

  • Specifications may change without notice — refer to manufacturer for final reference.
  • Verify photometric values and ANSI safety data from the official datasheet before specification use.

Downloads


Hydro Hybrid Cut Sheet   Download
Hydro Hybrid - DMX Traits   Download
Hydro Hybrid - User Manual   Download
Hydro Hybrid Photometric PDF Test Results.          Download
Hydro Hybrid IES Files   Download

Additional Details

SKU:
HYD869
UPC:
810087372507
Condition:
New
Width:
18.00 (in)
Height:
30.00 (in)
Depth:
14.00 (in)
