Description
The ADJ Hydro Hybrid** is a rugged, weather-resistant IP65-rated moving head luminaire that flexibly combines beam, spot, and wash functionality in a single unit. Powered by a 420W Osram SIRIUS HRI discharge lamp, it’s built for touring, outdoor events, festivals, and demanding installations. With full CMY color mixing, gobos, prisms, motorized zoom and focus, and a robust enclosure, it offers creative control and dependable performance in all conditions. :contentReference[oaicite:0]{index=0}
Light Source & Output
- 420W Osram SIRIUS HRI discharge lamp :contentReference[oaicite:1]{index=1}
- Up to ~14,416 lumens (typical published output) :contentReference[oaicite:2]{index=2}
- Full CMY color mixing system + 12-position color wheel (including CTO filters & UV) :contentReference[oaicite:3]{index=3}
Optics, Zoom & Beam Modes
- Motorized zoom / variable beam angles:
- Beam mode: approx. 1.6° – 17.7° :contentReference[oaicite:4]{index=4}
- Spot mode: approx. 3.1° – 39.2° :contentReference[oaicite:5]{index=5}
- Heavy frost filter for transforming beam/spot into wash output :contentReference[oaicite:6]{index=6}
- Two gobo wheels (rotating + static) with interchangeable glass/metal patterns :contentReference[oaicite:7]{index=7}
- Dual-plane prism effects (8-facet circular, 6-facet linear), overlay capability :contentReference[oaicite:8]{index=8}
- Animation wheel for dynamic projection effects :contentReference[oaicite:9]{index=9}
Control & Effects
- Standard DMX control (multiple channel modes) :contentReference[oaicite:10]{index=10}
- RDM compatible for remote addressing & device management :contentReference[oaicite:11]{index=11}
- Motorized focus, iris, strobe, and dimming with selectable curves :contentReference[oaicite:12]{index=12}
- Preprogrammed macros and automated / sound-active modes :contentReference[oaicite:13]{index=13}
- Aria X2 wireless management support (e.g. Bluetooth, OTA updates) :contentReference[oaicite:14]{index=14}
Electrical & Power
- Power input: AC 100–240V, 50/60Hz :contentReference[oaicite:15]{index=15}
- Max power consumption: ~580W :contentReference[oaicite:16]{index=16}
- Operating temperature range: –20 °C to 45 °C (–4 °F to 113 °F) :contentReference[oaicite:17]{index=17}
Housing & Mechanical
- IP65-rated enclosure — sealed and rugged for outdoor deployment :contentReference[oaicite:18]{index=18}
- Die-cast steel construction with durable housing :contentReference[oaicite:19]{index=19}
- Pan/tilt mechanical locks for transport security :contentReference[oaicite:20]{index=20}
- Integrated carry handles for easier handling :contentReference[oaicite:21]{index=21}
Dimensions & Weight
- Length (depth): 11.4” / 290 mm :contentReference[oaicite:22]{index=22}
- Width: 16.31” / 414.3 mm :contentReference[oaicite:23]{index=23}
- Height: 29.17” / 741 mm :contentReference[oaicite:24]{index=24}
- Weight: 69.7 lbs / 31.6 kg :contentReference[oaicite:25]{index=25}
What’s Included
- Hydro Hybrid moving head fixture
- PowerCON TRUE1 locking power cable
- Omega brackets (for truss / mounting)
- User manual
Use Cases
- Outdoor concerts, festivals, tours & live events
- Permanent outdoor installations (stadiums, theme parks)
- Large indoor venues requiring weather-resistant lighting
- Hybrid lighting setups needing beam, spot, wash in one unit
Notes & Disclaimers
- Specifications may change without notice — refer to manufacturer for final reference.
- Verify photometric values and ANSI safety data from the official datasheet before specification use.
