Focus Spot 7Z — Versatile & Powerful LED Moving Head Spot

The ADJ Focus Spot 7Z is a professional 420W LED moving head spot designed for versatility, performance, and creative flexibility. Featuring full CMY color mixing, motorized zoom, rotating gobos, prisms, and an animation wheel, the Focus Spot 7Z delivers stunning effects and precise projection. Whether you’re lighting a concert, theater stage, nightclub, or corporate event, this powerhouse fixture is engineered to meet the demands of professional production.

Highlights

• 420W white LED moving head spot fixture
• Full CMY color mixing + CTO for dynamic color control
• Motorized zoom range: 6°–48°
• Rotating and static gobo wheels for creative projections
• Animation wheel for dynamic textured effects
• Dual prisms: 4-facet circular and 6-facet linear (indexable & overlay)
• Frost filter for wash-style soft beam effects
• 0–100% smooth dimming with selectable curves
• Strobe and pulse effects with variable speed

Optics & Light Source

• Light Source: 420W LED engine (approx. 20,000 lumens output)
• Zoom Range: 6°–48° motorized
• Motorized focus and iris
• High CRI for excellent color rendering

Color & Effects

• CMY color mixing system with variable CTO
• Dichroic color wheel with 6 colors + open
• Rotating gobo wheel with 7 interchangeable gobos
• Static gobo wheel with 8 fixed patterns
• Animation wheel for advanced projections
• Two prisms (4-facet circular, 6-facet linear) with overlay capability
• Frost filter for soft-edge beam shaping

Control

• DMX512 with multiple channel modes
• RDM (Remote Device Management) compatible
• Art-Net & sACN support via Ethernet
• Built-in macros and automated programs
• Full-color LCD display with menu navigation

Connections

• DMX: 5-pin In/Out
• EtherCON ports for Art-Net/sACN
• Locking power In/Out (PowerCON TRUE1)

Electrical

• Multi-voltage: 100–240V, 50/60Hz
• Max Power Consumption: ~550W

Construction

• Durable housing built for touring and events
• Pan/Tilt locks for safe transport
• Compact and versatile for medium to large venues

Dimensions & Weight

• Dimensions (LxWxH): Approx. 17.3” x 13.2” x 26.6” (440 x 335 x 675 mm)
• Weight: 64 lbs. / 29 kg

What’s Included

• ADJ Focus Spot 7Z Fixture
• Locking power cable
• Omega brackets for mounting
• User manual

Use Cases

• Concerts and live touring productions
• Theater stage lighting
• Nightclubs and entertainment venues
• Corporate events and trade shows

Notes

• Specifications subject to change without notice.
