Description

The Platinum Quad Road Case is custom made to hold any (4) combinations of the following ELATION PLATINUM™ model fixtures:

Platinum Beam 5R™
Platinum Beam 5R EXTREME™
Platinum Beam 15R™
Platinum Spot 5R™
Platinum Spot 5R Pro™
Platinum Spot LED II™

FEATURES
Top Load Design
Hinged/Foamed Removable Lid with 9.5" Clearance for Trigger Clamps
Truck Pack: 1/3 Pack for 90" Box Truck | 1/3 Pack for 180" Truck
Holds any (2) combinations of the following Elation models:

SPECIFICATIONS
ATA Approved – All Hardware Flush Mount
1/2" Plywood Walls - ABS Exterior Finish
Tongue and Groove Sealing Extrusion
3/4" Plywood Base Plate
1/2" Divider Boards
2" Thick Foam
(4) 600# Rated High Impact Blue Casters
(4) High Impact Recessed Spring Latches
(8) Spring Loaded Handles
(8) High Impact Flat corners
(4) Stacking Cups
(1) Piano hinge

SIZE / WEIGHT
Length: 30” (762mm)
Width: 35.25” (895.4mm)
Vertical Height: 37” (939.8mm)
Weight: 134 lbs. (60.8 kg) EMPTY
Manufactured in the U.S.A.

Oversized item - Ships via truck only
