Description

The FUZE WASH Z350™ is a single source par moving head luminaire featuring a 350W Quad Color RGBW COB LED, 12° to 53° motorized zoom, pan and tilt, RGBW color mixing, variable dimming curve and strobe effects, DMX and RDM (remote device management) protocol support, DMX and power in/out connections, LCD menu display with 7 button control panel, multiple unit power linking, flicker free operation for TV and FILM, and a multi-voltage universal auto switching power supply (110-240v).

Features
350W RGBW COB LED Moving Head Wash Luminaire
RGBW Color Mixing
12° to 53° Wide Motorized Zoom Range
Variable Dimming Curves
Multiple Unit Power Linking
RDM (Remote Device Management)
Flicker Free Operation for TV and FILM

Specifications
SOURCE
350W RGBW COB LED
100,000 Hour Average Lamp Life*
*LED Life may vary depending on several factors including but not limited to:
Environmental Conditions, Power/Voltage, Usage Patterns (On-Off Cycling), Control, and Dimming.

PHOTOMETRIC DATA
26,240 LUX 847 FC @9.8’ (3m) (12° Full ON)
1,672 LUX 40 FC @9.8’ (3m) (53° Full ON)

COLOR
RGBW

EFFECTS
RGBW Color Mixing
12° to 53° Beam Zoom Range
Electronic Strobe, Dimming and Variable Dimming Curves
64 Color Presets and 14 Unique Color Macros

CONTROL / CONNECTIONS
4 DMX Channel Modes (19 Total Channels)
7 Button Control Panel and LCD Menu Display
RDM (Remote Device Management)
3pin/5pin DMX and powerCON In/Out

SIZE / WEIGHT
Length: 16.3" (414mm)
Width: 11.6" (294mm)
Vertical Height: 18.0" (461mm)
Weight: 45 lbs. (20.4 kg)

ELECTRICAL / THERMAL
AC 110-240V - 50/60Hz
380W Max Power Consumption
Multiple Unit Power Linking
5°F to 113°F (-15°C to 45°C)

APPROVALS / RATINGS
CE | RoHs | IP30

OPTIONAL ACCESSORIES:
FW350SNOOT - Snoot
