Description

Features:
High sensitivity and SPL
1 x 15" high power transducer with 50mm voice coil
1 x 1.7" diaphragm compression driver
Rotatable Horn: 50°-100° x 55° controlled coverage pattern
Built-in Bi-amp power amplifier module
Master volume control
Bass and Treble control
Heavy duty protective grill
XLR input and output connectors
Switchable between Mic and Line input
Injection molded
2 x XLR connectors
Suitable for use as a main system with or without sub speaker augmentation
Cabinet design for FOH and Monitor use
Portable system (stand), or permanent installation (wall, ceiling, under balcony)
Arrays with all active high power U Series sub speakers for extended low frequency, high quality music reproduction

Construction: Plastic

Transducers:
1 x 1.7" HF
1 x 15" LF

Frequency Response (-3dB): 40Hz-18kHz

Rated Power:
100W HF
300W LF (RMS)

Amplifier Type: Class H
Maximum SPL (1W @ 1m): 120dB (Peak)
Input Impedance: Balanced 20kΩ, Unbalanced 10kΩ
Rated Impedance: 8Ω
Dispersion (H x V): 50º-100º x 55º
Connector: 2 x XLR

Net Dimensions: 19.1" x 18.1" x 27.6"
Net Weight: 67.2 lbs.

Gross Dimensions: 21.5" x 20.3" x 31.5"
Gross Weight: 74.2 lbs.
