ArKaos PRO 4K Server w/ 4 x 4K Output Edit 1 HD-SDI Input

The powerful new ArKaos 4K Server features a dedicated synchronization hardware especially designed for Professional Lighting Designers and Production Studios.

Features
Plug and Play Simplicity
Vast library of high quality digital media from world’s best visual content providers
Comes installed with MediaMaster Pro
User-friendly management of frame lock and genlock

Smart Design
Runs 4K video
Four EDID managed outputs on DisplayPort 1.2 connectors
Dedicated hardware to synchronise the servers through genlock and frame lock
New interface allows users to operate genlock and frame lock from the front display
2x DVI
Fast and larger SSD drive
Large LED status strip for quick visual feedback on the server’s operation state
Server cooling and EDID can be managed directly from the front display
Fast recovery system by Acronis allows extremely simple reset from the boot menu
Pre-configured to work directly with all market-leading DMX lighting desks

Blistering Performance
Shock-resistant up to 2G
Easy access to fans and filters
Thoroughly tested in structural strength, and toleration of heat and vibration

Specifications
I/O
Interface Output: 1 (DP)
Output: 4 (DP)
EDID Management: Yes
Input (Standard): 1x HD-SDI
Input (Upgrade): Up to 4 x HD-SDI & 2 x DVI
Output Resolution: 4 x 4K
DMX 5pin Connectors: Yes
Genlock: No
Framelock: No
USB: 2 x USB 3.0 + 4 x USB 2
Balanced Audio In/Out (XLR): Yes
Network: 2

STORAGE
System Drive: SSD 128 GB
Separate Drive: SSD 256 GB

SOFTWARE
MediaMaster: Pro
CuePlayer (Theater mode): Yes
LED Mapper: Yes
Kling-Net Mapper: Yes
Video Mapper: Yes
Acronis Backup System: Yes
Layers Full HD: Up to 12
Layers HD: 12
Soft-Edge / Geometrical Correction; Yes

CONTROL
Control Display (Front Panel): Yes
LED Strip (Front Panel): Yes
DMX / MIDI / Keyboard: Yes
ArtNet / MA-Net: Yes

HARDWARE
Voltage: 107-240V Auto Switching
Professional Connectors: Yes

SIZE / WEIGHT
Height: 6.9” (176mm)
Length: 16.8” (426mm)
Depth: 20.0” (510mm)
Unit Weight 55.1 lbs. (25kg

Specifications and documentation subject to change without notice.
