Specifications
Light source: 100W RGBW COB LED Array
Lamp life: 60,000 hours
Luminous Flux: 8450 lumen, 11300 lux @ 2.5 m
Control: Remote on/off via DMX
Ballast: switching mode power supply
Beam angle: 13°

X/Y
Pan: 630° (4.0 sec) or 540° (3.58 sec), Tilt: 265° (2.8 sec)
16-bit resolution
Auto repositioning

Colors
8+open, interchangeable, indexable and bidirectional rainbow effect
Color bounce

Gobos
Outside ￠27mm, inside ￠22mm
7 + open custom interchangeable positions for rotating gobo wheel
7 + open fixed gobos
Real indexable and gobo shaking
Distinctive gobo animation effect

Features
DMX channels: 16/33/17/18
Color wheel: 8 + White
Static gobo wheel: 7 + Open
Rotation gobo wheel: 7 + Open
Motorized focus
Full range 0-100% dimmer
Various strobe
Rotating effect wheel 3 facet prism, 8 facet prism, and frost
Iris
RDM function to change DMX address, display flip, X/Y Reverse and more
Software upgrade via DMX
Hibernation when lost DMX for preset time
Indicate temperature info of base, arm and lamp
Fan speed auto change according to temperature

Display
2.4” LCD display with English/ Chinese/French/Spanish menu
Auto lock
Flip
Back-up communicating IC

Power
Max power consumption: 180W
Power supply: Electronic auto-ranging
Input voltage range: 100–240V, 50-60Hz
