Description
The DS1800 is a 1U, 2 in 4 out, or 1 in 8 out Distribution Amplifier.
Front Panel
Independent volume control to adjust each channel (concealed controls)
LED indicator for mode selection
LED signal indicators
Rear Panel
2 x Balanced XLR input connectors
8 x Balanced XLR output connectors
2 x XLR link connectors
Mode switch for 2 x 4 or 1 x 8
Input Connector: 2 x Balanced XLR
Output Connector: 8 x Balanced XLR, 2 x Balanced XLR Link
Input Impedance: Balanced 10kΩ
Maximum Output Levels: > ± 20dBu
Frequency Response (±0.3dB): 20Hz-20kHz
THD + N: <0.008%
S/N Ratio (A weight): >100dB
Dynamic Range: ≥ 115dB
Net Dimensions: 19″ x 6.8″ x 1.8″
Net Weight: 5.5 lbs
Gross Weight: 7.7 lbs
Additional Details
- SKU:
- B3-DS1800
- UPC:
- 22228880349
- Condition:
- New
- Width:
- 22.00 (in)
- Height:
- 9.00 (in)
- Depth:
- 3.00 (in)
