Elation ART500 DMX Touch Wall Panel LED Light Controller

The ART500™ is a touch panel DMX Controller with 1,024 DMX channels and 500 preset scenes, designed to be the most effective control solution for architectural control. Included is the ART500™ software package, which offers an easy to navigate interface, combined with powerful control features.

Features
The ART500™ is a touch panel DMX Controller with 1,024 DMX channels and 500 preset scenes, designed to be the most effective control solution for architectural control. Included is the ART500™ software package, which offers an easy to navigate interface, combined with powerful control features.

SPECIFICATIONS
Power Input: 6VDC (Transformer Included)
DMX Output: 1024 DMX Channels, 2 Universes
Software OS Compatibility:
Windows XP, Vista, 7, 8 (ESA Pro), Mac OS X (ESA2)
Trigger Protocols: 8 x Dry Contact Trigger, Calendar Trigger, RS-232, IR
Mounting: Single Gang Electrical Box (Not Included)
Housing: Glass Panel, Polycarbonate Body
Operating Temp: 14º - 113º F (-10º - 45º C)
Connectors: Screw Terminal Blocks and RJ45, USB Cable (Included)
Storage: Micro SD Card (Included)

 SIZE / WEIGHT
 Length: 4.17” (106mm)
 Width: 0.4” (11mm)
 Vertical Height: 5.7” (146mm)
 Weight: 0.5 lbs. (0.2kg)

 APPROVALS / RATINGS
 CE | cETLus | RoHs | IP20
