Description

Features:
High sensitivity and SPL
1 x 12" high power transducer with 50mm voice coil
1 x 1.7" diaphragm compression driver
90° x 60° controlled coverage pattern
Rotatable Horn: 50°-100° x 55 controlled coverage pattern
Heavy duty protective grill
2 x NL4 connectors
Injection molded
Suitable for use as a main system with or without sub speaker augmentation
Cabinet design for FOH and Monitor use
Portable system (stand), or permanent installation (wall, ceiling, under balcony)
Arrays with all active high power U Series sub speakers for extended low frequency, high quality music reproduction

Construction: Plastic

Transducers:
1 x 1.7" HF
1 x 12" LF

Frequency Response (-3dB): 50Hz-18kHz
Rated Power: 300W (RMS)
Sensitivity (1W @ 1m): 97dB
Rated Impedance: 8Ω
Dispersion (H x V): 50° x 100° x 55°
Connector: 2 x NL4

Net Dimensions: 16.3" x 15" x 24.4"
Net Weight: 39.7 lbs.

Gross Dimensions: 18.3" x 17.1" x 26.8"
Gross Weight: 44.1 lbs.
