Description
Kling-Force is the new hardware platform built by ArKaos, around the combination of a powerful processor and a hardware network switch. It creates a robust and efficient Kling-Net network. This platform is daisy chain-able to distribute video over Ethernet via plug and play and no complex setup is required. ArKaos Kling-Force DMX is an elegant and efficient solution to drive traditional DMX fixtures.
Features
It has 4 DMX outputs and so it can drive 4 DMX Universes and has 2 Ethernet connections allowing multiple units to be daisy chained.
With Kling-Force DMX you can assign as many fixtures as will fit within each DMX universes. This is done in the mapper where the user can pick any DMX fixtures and assign them a DMX address. Once this is done the fixtures become available as a devices in the Kling-Net Mapper.
Specifications
INPUT
Ethernet / Kling-Net Protocol
ETHERNET SWITCH
2 ports Hardware Gigabit Switch
DAISY CHAINING
Up to 50 devices
OUTPUTS
4 Universes
CONNECTORS
4x XLR 5pin Female
POWER SUPPLY
Not Included [Requires 5V]
RACK MOUNTING
Yes [7.0” (178mm) Rail Spacing]
SIZE / WEIGHT
Height: 7.5” (190mm)
Length: 5.1” (130mm)
Depth: 1.5” (39mm)
Unit Weight 1.05 lbs. (0.48kg)
Specifications and documentation subject to change without notice.
