Description

The ADJ WiFLY Bar QA5 is a Battery Powered Wireless Quad LED Linear Fixture with a built-in ADJ WiFLY Transceiver with wireless DMX. The rechargeable lithium battery is long lasting and safe to use. With a full charge you will receive up to six hours of life with five hours needed to fully charge it back to full life. The WiFLY Bar QA5 allows you to create rich hues and smooth color mixing for stage or wall washing. You can get a wide range of colors on your wall and set the mood to whatever you wish. The fixture uses LEDs rated at 50,000 hours with a maximum power draw of 58W. The fixture operates on AC or DC power.

The Transceiver will communicate with any remote for up to 400 feet in an open line of sight. You can run the device in six operational modes, Auto with a Program Run Mode, Sound Active Mode, RGBA Manual Control Mode, Static Color Mode, Slave Mode, and a DMX-512 Mode. Light up an entire wall with rays of light in a seemingly unlimited color palette. Perfect for those parts of the stage or club where wiring and other ways for power are inconvenient or just unsafe.

Specifications

Rechargeable Lithium battery powered, with wireless DMX, 20-inch / 0.502 meter ultra bright, indoor LED Linear Fixture with 5 x 5W Ultra bright QUAD (RGBA: 4-IN-1) LEDs
6 DMX Channels: 4, 6, 7, 8, 9 or 22 channels
6 operational modes: Auto (Program Run) Mode; Sound Active Mode; RGBA Manual Control Mode, Static Color Mode, Slave Mode and DMX-512 Mode
Variable RGBA color mixing offers a seemingly unlimited color palette - Great for Stage or Wall Washing!
Rechargeable Lithium battery built-in to fixture
Flicker Free
48 built-in Color Macros
LED pulse & strobe effect
DMX-512 Protocol
Electronic Dimming: 0 - 100%
Beam angle: 25-degree
Linkable via 3-pin XLR cable
4-button LED display on rear panel
IEC AC Power In/Out on rear to daisy chain power (Up to 10 units)
Includes built-in ADJ’s WiFly Transceiver Wireless DMX
Compatible with ADJ RFC remote control (sold separately)
Includes mounting brackets to mount on a wall or set on the ground
Long life LEDs (Rated at 50,000 hrs.)
Very low heat output
Run all night – No duty cycle
Rechargeable Lithium battery life: 6 hours full on (with a full charge); 5 hours charge time
Power Draw: 58W max
Multi-voltage Operation: AC 100V/60Hz - 240V/50Hz
Dimensions (LxWxH): 20” x 6” x 6” / 502 x 150 x 152mm
Weight: 9 lbs. / 4 kg.
