ADJ Vizi Beam RX2 Moving Head Beam Fixture

MSRP:
Was:
Buy Now! Buy Now: $999.99
(You save )
(No reviews yet) Write a Review
27 people looking at this.
Free Shipping - Usually shipps next business day!

Description

The Vizi Beam RX2 is a powerful, compact moving head beam fixture tailored for professional lighting needs. It features a robust 100W Osram Sirius HRI discharge lamp that produces a sharp 2-degree beam. With two prism effects and a range of advanced features, the Vizi Beam RX2 is designed to create dynamic and captivating light displays, making it an excellent choice for modern lighting professionals.

Light Source:
  • OSRAM Sirius HRI 100W Discharge Lamp (6,000 hr.)
  • Color temperature: 9000K (+/- 300K)
Features:
  • On-Board Wireless DMX
  • Motorized Focus + 16-bit fine focus
  • 2-degree beam angle
  • Frost Filter to create wash effect
  • High quality glass lens
  • 2 Rotating prisms:
  • 0-100% smooth dimming
  • Various strobe speeds
  • OTA, wireless, firmware updates
  • Fan cooled
Color Wheel:
  • 14 dichroic colors + white (Includes CTO (3200K), CTB (4500K & 9000K) & UV filters)
  • Indexable color wheel for split colors
GOBO Wheel:
  • 15 static GOBOs + open (3 GOBOs are beam reducers)
  • GOBO Shake Effect
Prism Wheels:
  • 2 Rotating prisms
  • 16- facet circular and 4-facet linear prisms
Control:
  • Protocols: DMX512 & RDM
  • Control Mode: DMX512 & Manual (On-board Controls)
  • 2 DMX Channel Modes: 12/16 Channels
  • Aria X2 Wireless Management / DMX System
  • Color LCD display with 4-button function menu
  • 0-100% smooth dimming
  • Various strobe speeds
  • With Wired Digital Communication Network
Pan/Tilt:
  • Pan: 540 degrees (plus 16-bit fine pan)
  • Tilt: 270 degrees (plus 16-bit fine tilt)
  • 3 Phase, High Speed, Pan/Tilt motors
Connections:
  • DMX Connections: 5-pin DMX In/Out (Data link max: 32 fixtures)
  • Power Connections: Outdoor locking In/Out connections to daisy chain power
Electrical:
  • Multi-voltage operation: 100-240V, 50/60Hz
  • Max power consumption: 168W (@120V), 157W (@230V)
  • Fuze Protected: 3.15A
Dimensions & Weight:
  • Dimension: 9” (L) x 12” (W) x 16.3” (H) (230 x 304 x 416mm)
  • Weight: 16.5 lbs. / 7.5 kg.
Approvals / Ratings
  • CE
  • cETLus (Control # 5028947)
  • FCC
What’s Included:
  • 2x Omega Brackets (107 Type)
  • 2M, outdoor locking 14AWG power cord
Specifications are subject to change without notice.

Downloads

ADJ Vizi Beam RX2 - 3D Cad   Download
Vizi Beam RX2 - User Manual.        Download
Vizi Beam RX2 - DMX Traits   Download



Additional Details

SKU:
VIZ250
UPC:
810087372484
Condition:
New
Width:
12.00 (in)
Height:
14.00 (in)
Depth:
18.00 (in)
