Description
The Vizi Beam RX2 is a powerful, compact moving head beam fixture tailored for professional lighting needs. It features a robust 100W Osram Sirius HRI discharge lamp that produces a sharp 2-degree beam. With two prism effects and a range of advanced features, the Vizi Beam RX2 is designed to create dynamic and captivating light displays, making it an excellent choice for modern lighting professionals.
Light Source:
- OSRAM Sirius HRI 100W Discharge Lamp (6,000 hr.)
- Color temperature: 9000K (+/- 300K)
Features:
- On-Board Wireless DMX
- Motorized Focus + 16-bit fine focus
- 2-degree beam angle
- Frost Filter to create wash effect
- High quality glass lens
- 2 Rotating prisms:
- 0-100% smooth dimming
- Various strobe speeds
- OTA, wireless, firmware updates
- Fan cooled
Color Wheel:
- 14 dichroic colors + white (Includes CTO (3200K), CTB (4500K & 9000K) & UV filters)
- Indexable color wheel for split colors
GOBO Wheel:
- 15 static GOBOs + open (3 GOBOs are beam reducers)
- GOBO Shake Effect
Prism Wheels:
- 2 Rotating prisms
- 16- facet circular and 4-facet linear prisms
Control:
- Protocols: DMX512 & RDM
- Control Mode: DMX512 & Manual (On-board Controls)
- 2 DMX Channel Modes: 12/16 Channels
- Aria X2 Wireless Management / DMX System
- Color LCD display with 4-button function menu
- 0-100% smooth dimming
- Various strobe speeds
- With Wired Digital Communication Network
Pan/Tilt:
- Pan: 540 degrees (plus 16-bit fine pan)
- Tilt: 270 degrees (plus 16-bit fine tilt)
- 3 Phase, High Speed, Pan/Tilt motors
Connections:
- DMX Connections: 5-pin DMX In/Out (Data link max: 32 fixtures)
- Power Connections: Outdoor locking In/Out connections to daisy chain power
Electrical:
- Multi-voltage operation: 100-240V, 50/60Hz
- Max power consumption: 168W (@120V), 157W (@230V)
- Fuze Protected: 3.15A
Dimensions & Weight:
- Dimension: 9” (L) x 12” (W) x 16.3” (H) (230 x 304 x 416mm)
- Weight: 16.5 lbs. / 7.5 kg.
Approvals / Ratings
- CE
- cETLus (Control # 5028947)
- FCC
What’s Included:
- 2x Omega Brackets (107 Type)
- 2M, outdoor locking 14AWG power cord
Specifications are subject to change without notice.
