Description

The ADJ Vizi Beam 5RX was designed to be compact and very powerful at the same time, The Vizi Beam 5RX features super fast and accurate motorized focus optics, PowerCon power connectors for In/Out to daisy chaining the power to the lights, frost filter to turn the hard edge beams to a wash profile and a 8-facet prism and stepper motors for speed and accuracy and quick precise movement

The light also features a powerful new and revolutionary Philips Platinum 5R 189W discharge lamp technology (8000˚K, 3,000 hr). that expands the color dynamics and color mixing. The powerful Platinum 5R has an output comparable to a 575W fixture, with double the output. It also offers a flat, even spot light field for a better saturation of colors.

The Vizi Beam 5RX is super fast compared to some previous ADJ moving heads because it is much lighter in weight and more compact than other moving heads in its class. It’s has a very tight, 5-degree beam angle with extreme light output that makes it ideal for applications where a small beam is necessary.

Specifications
• 2 DMX Channel Modes: 16 or 19 DMX channels
• Gobo scroll mode
• LED DMX 4-Button menu system
• 5-degree beam angle
• Auto X-Y repositioning
• 14 colors + white and Split Colors
• 17 static, fixed gobos + spot
• 8-facet Prism with macros
• Gobo Shake effect
• Independent gobo and color wheels
• Pan: 540-degree
• Tilt: 270-degree
• Pan/Tilt Invert
• Built-In Pan/Tilt Macros
• 16-Bit Pan/Tilt Positioning
• Motorized focus
• Shutter: Pulse effect; random strobe slow to fast
• Electronic Dimming: 0% - 100%
• Strobe effect
• Frost Filter
• Stepper motors with micro stepping
• Omega Quicklock Brackets included
• DMX: 3-pin XLR In/Out
• LUX: 770000 @ 5M, 220000 @ 10M
• Powercon In/Out to daisy chain power
• Multi-voltage Operation: 100-240V, 50Hz/60Hz
• Lamp: Philips® Platinum 5R 189W discharge, 8,000˚K – 3,000 hr. long life
• Dimensions (LxWxH): 394x325x522mm / 15.5” x 12.75” x 20.5”
• Weight: 19 kg. / 42 lbs
