The ADJ UBL6H Ultra Series RGBAL+UV LED Linear Wash Bar is a professional lighting fixture designed to illuminate walls, floors, ceilings, stages, backdrops, and architectural features with rich color and precise control. Ideal for weddings, concerts, nightclubs, theaters, corporate events, mobile DJs, and permanent lighting installations, this compact linear LED wash light delivers versatile performance for professional event and entertainment lighting.

Equipped with six powerful 20-watt HEX LEDs combining Red, Green, Blue, Amber, Lime, and UV, the UBL6H produces vibrant saturated colors, smooth pastel tones, and high-quality white light. The additional Lime LED improves color accuracy, delivering a Color Rendering Index (CRI) greater than 90. Adjustable white color temperature from 2,300K to 9,900K allows lighting designers to create warm ambient environments or crisp, cool white illumination.

A focused 17-degree beam angle provides controlled lighting for wall washing, uplighting, and accent applications, while the included 20-degree diffusion filter offers additional flexibility. Built-in horizontal magnetic alignment makes positioning multiple fixtures easier for continuous linear lighting designs. Three independently controllable LED pixel groups, seven DMX channel modes, RDM compatibility, and multiple dimming options provide extensive creative control.

The ADJ UBL6H features an OLED display, built-in color macros, sound-activated operation, 5-pin DMX connections, and locking power input/output for linking multiple fixtures. The included UC-IR24 infrared remote and mounting brackets make this versatile fixture suitable for both portable productions and professional indoor installations.

Features

• Professional Ultra Series RGBAL+UV HEX LED linear wash bar
• Six ultra-bright 20W LEDs with Red, Green, Blue, Amber, Lime, and UV color mixing
• Lime-enhanced LED technology for accurate, natural-looking colors and white light
• High Color Rendering Index (CRI) greater than 90
• Adjustable white color temperature from 2,300K to 9,900K
• 17-degree native beam angle for focused wash lighting and uplighting
• Includes 20-degree diffusion filter for additional beam control
• Built-in horizontal magnetic alignment for arranging fixtures side by side
• Three independently controllable groups of two HEX LEDs in supported DMX modes
• Seven DMX channel configurations and RDM compatibility
• Five operational modes: Auto Run, Program, Sound Trigger, RGBAL+UV Manual, and DMX-512
• 64 built-in color macros
• Six selectable dimming modes and four dimming curves
• Electronic 0–100% dimming with LED pulse and strobe effects
• Built-in microphone for sound-triggered effects
• OLED display with four-button control interface
• 5-pin XLR DMX connections and locking power input/output
• Compatible with included ADJ UC-IR24 remote with a range up to 32.8 feet
• LED operating life rated at approximately 50,000 hours
• Mounting brackets included for floor placement or attachment to a truss clamp
• IP20-rated construction for indoor applications

Specifications

General Information

• Manufacturer: ADJ Lighting
• Product Series: Ultra Series
• Model: UBL6H
• Manufacturer SKU: UBL600
• UPC: 810087371913
• Fixture Type: LED Linear Wash Bar
• Application: Professional indoor stage, event, and architectural lighting

Light Source & Optical Performance

• LED Light Source: 6 x 20W ultra-bright HEX LEDs
• LED Colors: Red, Green, Blue, Amber, Lime, UV (RGBAL+UV)
• Rated LED Life: Approximately 50,000 hours
• Beam Angle: 17 degrees
• Color Rendering Index: CRI >90
• Adjustable Color Temperature: 2,300K to 9,900K
• Pixel Pitch: 85.5 mm
• Color Mixing: Smooth RGBAL+UV HEX color mixing

Control & Programming

• Control Protocol: DMX-512
• RDM Support: Yes
• DMX Channel Modes: 6, 11, 13, 16, 18, 25, and 28 channels
• DMX Pixel Control: 3 groups of 2 RGBAL+UV LEDs in 18-, 25-, and 28-channel modes
• Operational Modes: Auto Run, Program, Sound Trigger, RGBAL+UV Manual, DMX-512
• Display: OLED display with four control buttons
• LED Refresh Rate: 1.9 kHz
• Built-In Color Macros: 64
• Dimming Modes: Standard, Stage, TV, Architectural, Theatre, Stage 2
• Dimming Curves: Square, Linear, Inverse Square, S-Curve
• Electronic Dimming: 0–100%
• Effects: LED Pulse and Strobe
• Sound Activation: Built-in Microphone
• Infrared Remote: ADJ UC-IR24
• Remote Operating Range: Up to 32.8 ft. (10 m)
• Alignment: Built-in Horizontal Magnetic Alignment

Connections & Power

• DMX Connectivity: 5-pin XLR
• Power Connections: Locking Power Input and Output
• Input Voltage: AC 100–240V, 50/60Hz
• Manufacturer-Stated Power Draw: 26W
• Power Linking at 120V: Up to 26 UBL6H fixtures
• Power Linking at 230V: Up to 50 UBL6H fixtures

Physical Specifications

• Dimensions (Manufacturer L x W x H): 3.0 x 22.4 x 4.2 inches
• Manufacturer Metric Dimensions: 75 x 596 x 106.7 mm
• Weight: 4.41 lbs. (2 kg)
• IP Rating: IP20 – Indoor Use
• Certifications: cETLus (Control #4002034), CE, FCC

Environmental Specifications

• Operating Temperature: -4°F to 104°F (-20°C to 40°C)
• Storage Temperature: -22°F to 113°F (-30°C to 45°C)
• Environment: Indoor use only; protect from moisture and precipitation

What's Included

• (1) ADJ UBL6H RGBAL+UV LED Linear Wash Bar
• (1) Indoor Locking Power Cord
• (1) ADJ UC-IR24 Infrared Remote Control
• (1) 20-degree Diffusion Filter
• Mounting brackets for floor placement or truss clamp attachment

Optional Accessories

Additional diffusion accessories are available separately for adjusting the beam coverage:

• ADJ UBL613: 1 x 40-degree Linear Diffusion Lens
• ADJ UBL640: 40-degree Linear Diffusion Lens
• ADJ UBL660: 60-degree Linear Diffusion Lens

Product Downloads & Technical Documentation

Access manufacturer documentation, installation drawings, lighting performance data, and DMX programming information for the ADJ UBL6H.

• ADJ UBL6H User Manual (PDF)
• ADJ UBL6H Product Cut Sheet (PDF)
• ADJ UBL6H DMX Traits (PDF)
• ADJ UBL6H Dimensional Drawing (PDF)
• ADJ UBL6H 2D CAD Drawing (DWG)
• ADJ UBL6H 3D CAD Drawing (DWG)
• ADJ UBL6H IES Lighting Files (ZIP)
• ADJ UBL6H Photometric Data (ZIP)

Manufacturer specifications are subject to change without notice. Refer to the current ADJ product manual and documentation for installation, electrical requirements, and operating instructions.
