TASCAM VS-R264 Full HD AV Over IP Streaming Encoder / Decoder

The VS-R264 is a Full HD AV over IP streaming encoder and decoder that simultaneously records, encodes, streams, and decodes Full HD video streams (1920x1080) using H.264 long GOP encoding with bit rates up to 30 megabits over standard networks suitable for 100Mbps or 1Gbps.

V1.1.0 adds support for three simultaneous RTMP streams for distribution to multiple platforms, as well as simultaneous backup distribution to the server of the same streaming service.
The total number of simultaneous streams is eight (3 x RTMP / RTMPS、 1 x RTSP、1 x HLS、2 x RTP / UDP Unicast, 1 x RTP / UDP Multicast)

The VS-R264 live stream encoder addresses the growing demand for an external stand-alone YouTube encoder in live streaming environments. Additionally, the VS-R264 provides Full HD streaming to popular Content Delivery Networks (CDNs) including Wowza, Ustream, AWS Elemental MediaLive and CloudFront, to name a few.
The half-rack size VS-R264 functions as a stand-alone unit—no external computer is needed for recording or streaming.

Notice for Copyright
Creative works as picture images, movies, music and others are to be protected by applicable copyright laws, and when you intend to use those works in recording, reproducing, broadcasting or other means for the purpose of commercial use, you are required to obtain the license by copyright owners therefor. The license terms might be different in each occasion and the copyright owner. Please be advised that you contact your content service providers and/or applicable copyright management organization.

Notice for Streaming
In case of your streaming for commercial purpose, unlike for personal use, you might be required to conclude the specific service agreement with your content service providers or your content service provider may not allow commercial use in general. Please check the terms of use of the content service provider in choosing your content service provider.

Balanced analog Euroblock/Phoenix low voltage wire connectors and unbalanced analog 1/8" (3.5mm) mini-stereo jacks provide versatile audio I/O connections for a wide range commercial AV over IP environments, including corporate, education, house of worship, government, industrial and security.

V1.1.0 adds support for three simultaneous RTMP streams for distribution to multiple platforms, as well as simultaneous backup distribution to the server of the same streaming service.

The total number of simultaneous streams is eight (3 x RTMP / RTMPS、 1 x RTSP、1 x HLS、2 x RTP / UDP Unicast, 1 x RTP / UDP Multicast)

Output selectable from various streams
The decoder can receive RTP, UDP unicast, RTP/UDP multicast, RTMP/RTMPS, and HLS streams. The selected stream will be decoded, and the audio and video will be output through the HDMI terminal. In addition, audio can be simultaneously output through the balanced (Euroblock) and unbalanced (3.5mm stereo mini jack) audio outputs.

The Mac/Windows "TASCAM DISCOVERY" app allows multiple VS-R units connected to the network to be managed from a simple Web-browser based GUI. All configuration settings are saved within the VS-R devices, so that in normal operation no computer is needed for streaming or recording.

PoE+ functionality eliminates the need for AC adaptors in AV installations. Optional TASCAM AC power supply sold separately where external AC power is required.

Power supply also can be done by the optional AC adapter (TASCAM PS-P1220E; sold separately)

Features at a glance
Full HD AV over IP streaming media encoder and decoder for live video streaming.
Simultaneously records, encodes, streams, and decodes Full HD (1920x1080p) video streams.
Functions as an external stand-alone encoder for live Full HD streaming environments.
Provides Full HD live video streaming (1920x1080) to Content Delivery Networks (CDNs) including YouTube, Wowza, Ustream, AWS Elemental MediaLive and CloudFront, etc.
Perfect for a wide range of live streaming AV installations and environments, including corporate, education, house of worship, government, industrial installations and security.
H.264 long GOP encoding with bit rates up to 30 megabits over standard networks suitable for 100Mbps or 1Gbps.
Compatible with major streaming protocols such as RTMP, RTSP and HLS.
Unicast and multicast streaming support.
Multiple Simulcast and backup enabled by 3 RTMP Streams Simultaneously.
The total number of simultaneous streams is eight.
* The streaming performance depends on the resolution settings, transfer rate, and network environment.
Offers RESTful API for integration into control systems in commercial AV installations.
Versatile audio I/O connections via balanced analog Euroblock low-voltage wire connectors and unbalanced analog 1/8" (3.5mm) mini-stereo jacks.
Audio can be embedded from analog sources and de-embedded to drive networked audio playback for ceiling speakers.
Provides digital audio embedded within the HDMI I/O.
Installed output level configuration function and reference level switching function (up to +20dBu) allows reliable and flexible system structuring.
Ability to record directly to USB connected media or SD cards via a front panel loading slot.
Recorded files can easily be uploaded to an FTP server automatically for creating back-up copies or repurposing to the web.
Web browser based remote control to configure unit settings.
Supports Gigabit Ethernet.
Support PoE+ for power supply in addition to the optional AC adapter (TASCAM PS-P1220E; sold separately)
Compact half-rack size. Included surface rack mountable angles allow installation on different usage scenes and environments.
With the optional rack-mountable shelf AK-RS1, up to two VS-R units can be installed in a 19 inch rack space.
