TASCAM TM-80 Studio Condenser Microphone

TASCAM TM-80 – Studio Condenser Microphone (Cardioid) for Home Recording

The TASCAM TM-80 is a studio condenser microphone designed and priced for home recording, delivering a rich, full sound for vocals and acoustic instruments. Built around an 18mm pure aluminum diaphragm and a cardioid pickup pattern, it captures detail with clarity while helping keep room ambience under control. With internal circuitry optimized to reduce noise and distortion, the TM-80 is a strong all-around choice for project studios, streaming setups, and desktop recording.

Highlights

• Cardioid condenser design ideal for vocals and instruments
• 18mm pure aluminum diaphragm for detailed, natural capture
• Wide frequency response: 20Hz–20kHz
• High max SPL: 136dB (at 1kHz, 1% THD) — suitable for louder sources like guitar amps and drums
• Optimized internal circuitry for lower noise and reduced distortion
• Phantom power required: DC 9–48V

Included Accessories

• Shock-absorbing suspension (shockmount)
• Mini desk stand
• Mic cable: 6 ft / 1.8m (XLRM–XLRF)
• Owner’s manual (including warranty)

Specifications

• Model: Condenser
• Polar Pattern: Cardioid
• Frequency Response: 20Hz to 20,000Hz
• Sensitivity: -38dB ±2dB (0dB = 1V/Pa at 1kHz)
• Phantom Power Requirement: DC 9–48V
• Output Impedance: 200Ω ±30% (at 1kHz)
• Load Impedance: > 1kΩ
• Self Noise: 17dB A
• Max SPL: 136dB (at 1kHz = 1% THD)
• S/N Ratio: 77dB
• Housing: Die cast zinc
• Dimensions (Ø × L): Ø1.9" × 6.5" / Ø48 × 165 mm
• Weight: 10.6 oz / 300 g

Specifications are subject to change without notice.
