Description
FEATURES
System 12 Vdc / PWM dimmer (4-Channel)
Control Options DMX-512, Stand Alone
Load Max 150W connect to Driver Max 75W connect to 1 output
Addressing DMX Dipswitch
Power Requirement / 110 Vac (3.2A) / 240 Vac (1.6A)
DMX Input: 3-pin XLR
DMX Output: 3-pin XLR
DMX Channels: Min. 24 (8 x RGB), Max. 32 (8 x RGBW)
Listing CE and cETLus certified
Operating Temp. 0 degreeC ~ +40 degreeC
Storage Temp. -20 degreeC ~ +70 degreeC
Housing Sheet metal with powder painting
Dimensions: 286 (L) x 191 (W) x 74 (H) mm Weight: 3,0kg 26-044-0032-00 -
AL-DRIVER 8RGBW 24 v DC - for standard 24v+ DC LED
Additional Details
- SKU:
- DPW-111-DA
- UPC:
- Condition:
- New
- Width:
- 3.00 (in)
- Height:
- 3.00 (in)
- Depth:
- 2.00 (in)
